Nobeltec TZ Navigator Furuno Radar Module - Digital Download

TZ Navigator Furuno Radar Module - Digital Download

INTEGRATE TIMEZERO SOFTWARE WITH BEST-IN-CLASS FURUNO RADARS AND MFDS
The Furuno Radar Plus Pack allows the user to make the most of compatible FURUNO radars and MFDs. Combine FURUNO hardware with TIMEZERO for a powerful navigation solution.

The commercial-grade FAR 2xx7 series of radars can be integrated with TIMEZERO software, responding to professional user needs.

Recreational users on the other hand, will be impressed by the advanced integration available with the acclaimed NavNet 3D and TZtouch MFDs. The FURUNO DRS (Digital Radar Sensors) that are on the NavNet network can be fully integrated with TIMEZERO software, enabling the display, control and overlay of the radar from within the software.

TIMEZERO software connects to the NavNet network and receives navigation data directly from the network.Combining the NavNet and TIMEZERO software systems results in an extremely fast and user-friendly solution.

Features:
When the FURUNO Radar Plus Pack is added to your TIMEZERO software a range of functionalities are unlocked, between your FURUNO radar or MFD and software.

TIMEZERO navigation software can be connected to a Furuno NavNet3D or TZtouch network allowing full control of the DRS radars (with an MFD present on the network). This means that you can display the radar image directly in TIMEZERO software, enjoy full control of the software from your software, and overlay the radar image on your charts. Radar overlay is an effective safety tool that allows you to understand your surroundings in relation to your current position.

When TIMEZERO is connected to a NavNet3D network, the following capabilities are enabled:

Reception of all navigation information (Position, COG/SOG, Heading, Wind, AIS, etc.) from the NavNet3D Network

Real-Time synchronization of the Active Route among the PC and every NavNet3D MFD display on the network

Exchange Routes and Waypoints from the PC to NavNet3D MFD(s) over the network

Share charts between the NavNet3D and TIMEZERO software

Enable the Chart Server for the NavNet3D MFD(s)

View and control the DRS Radar (*)

When TIMEZERO is connected to a NavNet TZtouch network, the following capabilities are enabled:

Reception of all navigation information (Position, COG/SOG, Heading, Wind, AIS, etc.) from the NavNet TZtouch Network

Real-Time synchronization of the Active Route between the PC and every TZtouch MFD display on the network

Share charts between the NavNet3D and TIMEZERO software

Display and control of the DRS Radar (*)

(*) MFD must be present on the network

The Plus Pack also enables connection to a Furuno FAR2XX7 series radar when this optional Furuno Radar Plus Pack is unlocked. These commercial-grade radars have an Ethernet connection that makes the connection to TIMEZERO possible, and enables the following capabilities:

View and control the Furuno 2XX7 Radar from your PC

Acquire and display ARPA targets

Receive Position, COG/SOG, Heading data from the FAR2XX7 Network
