Newmar PT-80 Battery Charger

The Newmar Power PT-80 is a Phase Three Series battery charger for 12-volt marine electrical systems. It provides smart three-stage charging and selectable settings for gel-cell, flooded lead-acid, or AGM batteries.

• Model: PT-80
• System voltage: 12-volt
• Charging stages: bulk, absorption, and float
• Battery type settings: gel-cell, flooded lead-acid, and AGM
• Input VAC: 90-264 VAC, 50-60 Hz
• Input amps at full load: 12 amps at 115 VAC; 7 amps at 230 VAC
• Power factor: .95 at 230 V or .98 at 115 V
• Maximum output: 80 amps
• Output banks: 3 isolated banks
• Battery capacity: 160-800 amp-hours
• Operating temperature reference: T-7
• Temperature range: -10 degrees C to +60 degrees C
• Derating: 100% at 50 degrees C to 80% at 60 degrees C, linearly
• Case: stainless steel with white powder coat finish
• Weight: 15.2 lb / 7 kg
• Optional temperature sensor model: TCS-12/24
• Remote panel model: RP
• Equalize option: yes
• Compliance reference: CE
• Protection: current limiting, thermal protection, forced air cooling, and drip shield
• Nominal gel-cell output voltage without temperature compensation: 14.0 V
