Newmar PT-40U Battery Charger

The Newmar PT-40U is a Phase Three Series battery charger for 12-volt marine systems. It is designed for workboats, military vessels, commercial vessels, and recreational craft, with selectable charging for gel-cell, flooded lead-acid, or AGM batteries.

• Brand: Newmar Power
• Model: PT-40U
• System voltage: 12-volt
• Charging stages: Bulk, absorption, and float
• Battery type selection: Gel-cell, flooded lead-acid, or AGM
• Input VAC: 90-264 VAC, 50-60 Hz
• Input amps at full load: 6.8 at 115 VAC; 3.4 at 230 VAC
• Power factor: .98 at 115V and .95 at 230V
• Maximum output: 40 amps
• Output banks: 3 isolated banks
• Battery capacity: 80-400 amp-hours
• Case: Stainless steel with white powder coat finish
• Case size: 13.85 x 9.5 x 4.8 inches; 35.2 x 24.1 x 12.2 centimeters
• Weight: 11 lb / 6 kg
• Operating temperature: -20°C to +70°C
• Temperature derating: 100% at 50°C to 50% at 70°C, linear
• Protection: Current limiting, thermal protection, forced air cooling, and drip shield
• Optional temperature sensor: TCS-12/24
• Remote panel model: EVM-12-2
• Equalize option: No
• Approval: ABS-type approval for battery charging and power supplies
• Drip shield note: With drip shield installed, add .75" to height and 1.35" to depth
