Newmar PT-24-13W Battery Charger

Newmar Power PT-24-13W Battery Charger is a marine charger for 24-volt battery systems on workboats, military vessels, commercial vessels, and recreational craft. It uses three-stage charging and selectable battery settings to support gel-cell, flooded lead-acid, or AGM batteries.

• 24-volt battery charger with 13 amp maximum output
• Three-stage charging: bulk, absorption, and float
• Battery type selector for gel-cell, flooded lead-acid, and AGM settings
• Three isolated output banks with ammeter for total output current
• Battery capacity range: 26 to 130 amp-hours
• Input VAC, 50-60 Hz: 90-132 or 180-264
• Input amps at full load: 6.5 at 115 VAC; 4 at 230 VAC
• Power factor: .7
• Can be used as a power supply and can power loads without a battery in line
• Current limiting helps prevent overload damage
• Protection includes current limiting, thermal protection, forced air cooling, and drip shield
• Stainless steel case with durable white powder coat finish and marinized internal circuitry
• Case size reference: A-1
• Case size: 11.2 x 7.7 x 4.75 inches (28.4 x 19.6 x 12.1 centimeters)
• With dripshield installed, add 1.1 inches (2.8 cm) to height and .92 inches (2.3 cm) to depth
• Weight: 8 lb (4 kg)
• Operating temperature rating reference: T-2
• Temperature range: -10 degrees C to +60 degrees C
• Derates linearly from 100% at 50 degrees C to 60% at 60 degrees C
• Optional temperature sensor model: TCS-12/24
• Remote panel model: RP
• Install in conjunction with PT-MCU for additional control and monitoring
• Compliance reference: CG, ABS
• ABS-type approval for battery charging and power supplies
• Nominal gel-cell output without temperature compensation: 28.0 VDC charge at 50% load and 27.2 VDC float at .5 amp load
• Nominal flooded/AGM output without temperature compensation: 28.4 VDC charge at 50% load and 26.8 VDC float at .5 amp load
