Newmar GI-30-FS Galvanic Isolator 30A Fail Safe

The Newmar GI-30-FS is a 30A fail-safe galvanic isolator for boats with shore power systems. It installs between the AC safety ground and DC bonding system to block low-voltage galvanic currents while maintaining the safety ground path.

• Product type: galvanic isolator
• Model: GI-30-FS
• Rating: 30A
• Shore power voltage: 115-230V
• Maximum short circuit: 5000 amps
• Stray current protection: up to 1.4 VDC
• Fail-safe design: maintains ground connection in the event of isolator failure
• Safety path: includes a large capacitor as a secondary low-impedance AC path to ground
• Standard: certified to UL1500 for ignition protection
• Testing: tested to 50 degrees C ambient temperature
• ABYC: meets ABYC A-28 2019 requirements
• Dimensions: 200 x 189 x 68.5 mm
• Return note: this product may not be returned to the original point of purchase; contact the manufacturer for issues or concerns
