• Marinco Wiper Motor 1000 Series - 12V - 1.5" Shaft - 80°
1 1

Marinco

Marinco Wiper Motor 1000 Series - 12V - 1.5" Shaft - 80°

Marinco Wiper Motor 1000 Series - 12V - 1.5" Shaft - 80°

OM-MARINCO-WIPERMOTOR1000-36180

$162.67
$306.99 $162.67
Sale
FREE Standard Shipping On every U.S. order — no minimum. Faster delivery options are available at checkout for qualifying orders.

Low stock: 1 left
Free standard shipping · every U.S. order, no minimum
Authorized Marinco Dealer
Genuine product · full manufacturer warranty
Secure checkout via Shopify Payments
View full details

Overview

The Marinco 1000 Series wiper motor is a 12V waterproof motor for boat windshield wiper systems. This version has a 1.5" shaft and an 80 degree factory sweep, with adjustable sweep options for matching the installation.

  • Brand: Marinco
  • Series: 1000
  • Voltage: 12V
  • Shaft length: 1.5", including 0.5" of knurled arm fitting
  • Shaft diameter: 0.625" / 16 mm
  • Factory sweep: 80 degrees
  • Adjustable sweep settings: 50 degrees, 65 degrees, 80 degrees, or 110 degrees
  • Housing: Fully sealed waterproof housing made from UV-stabilized, high-temperature, high-impact thermoplastic
  • Drive details: Anti-rotation drive shaft, knurled drive shaft, and solid brass arm drive nut
  • Parking: Coast-to-park with adjustable right or left self-parking
  • Included in retail version: 5 amp fuse and holder; on/off switch not included
  • Circuitry: RF shielded
  • Approximate size: 6.625" L x 3.375" W x 2" D
  • Weight: 1.75 lb
  • Stall torque: 55 in-lb / 63 kgf-cm / 6.2 Nm
  • Stall current: 9.8-10.0 amps
  • No-load current: 0.8-1.2 amps+
  • Arm and blade capacity: Powers 18" Deluxe arm and 18" Deluxe blade combinations at sweep settings of 80 degrees or less, or 16" Deluxe arm and 16" Deluxe blade combinations at 110 degrees

Specifications

BrandMarinco
Manufacturer part #36180
UPC035028361802
Boxed dimensions10 x 7 x 6 in
Shipping weight2.4 lb
