Egis M-Series 300A Battery Switch Off/On Knob Actuator
Egis M-Series 300A Battery Switch Off/On Knob Actuator
SKU:OM-EGISMOBILEEL-MSERIES300A-2306
Low stock: 3 left
Couldn't load pickup availability
Overview
Control your boat's battery connection with the Egis Mobile Electric M-Series 300A switch and its off/on knob actuator. Sealing against dust and water intrusion and ignition protection support installation in demanding electrical environments.
Key features
- Dust and water sealing helps protect the switch from intrusion.
- Ignition protection allows installation in closed compartments where explosive gases may be present.
- Serrated flange lock nuts help keep cable terminals from loosening under vibration.
- Multiple mounting configurations accommodate different installation layouts.
- Stainless steel hardware and high-temperature materials suit harsh operating environments.
Specifications
- Brand: Egis Mobile Electric
- Series: M-Series
- Switch rating: 300A
- Actuator: Off/on knob
- Maximum voltage, single circuit: 48 Vdc
- Maximum voltage, selector / dual circuit: 32 Vdc
- Stud size and thread: 3/8-inch-16
- Terminal stud torque: 120 in-lbs (13.6 N-m)
- Accepted ring terminal size: 3/8 inch (M10)
- Mounting hole fastener size: #10 screw
- Live switching rating: 25 Amps
- Ignition protection rating: SAE J1171 / ISO 8846
- Bulkhead mounting hole size: 2-5/8 inches
- Panel mounting hole size: 2-5/16 inches
- Cable size required to meet rating: 4/0 AWG
Specifications
| Brand | Egis Mobile Electric |
|---|---|
| Manufacturer part # | 2306 |
| UPC | 850067590507 |
| Boxed dimensions | 7 x 5 x 4 in |
| Shipping weight | 0.75 lb |
