• Bluewater 22mm Push Button Switch - Off/(On)/(On) Double Momentary Contact - Blue/Green/Red LED - 4' Lead
  • 103888
1 2

Bluewater

Bluewater 22mm Push Button Switch - Off/(On)/(On) Double Momentary Contact - Blue/Green/Red LED - 4' Lead

Bluewater 22mm Push Button Switch - Off/(On)/(On) Double Momentary Contact - Blue/Green/Red LED - 4' Lead

OM-BLUEWATER-22MMPUSHBUTTON-905921234

$74.46
$74.46
FREE Standard Shipping On every U.S. order — no minimum. Faster delivery options are available at checkout for qualifying orders.

Low stock: 3 left
Free standard shipping · every U.S. order, no minimum
Sourced from authorized U.S. distributors
Genuine product · full manufacturer warranty
Secure checkout via Shopify Payments
View full details

Overview

(ON)-(ON)-OFFAction
Blue/Green/RedColor

For boat dash controls that call for two momentary on states, Bluewater offers this 22mm Off/(On)/(On) push button switch. Its blue, green and red LEDs distinguish the off, first-on and second-on states at a glance.

Key features

  • Double momentary contact supports an Off/(On)/(On) control arrangement.
  • Three LED colors help you distinguish each operating state in low light.
  • The supplied gasket combines with the switch housing to achieve an IP69K waterproof rating.
  • A 4-foot lead gives you length to route the connection behind the dash.
  • Color-coded button contacts simplify identification when wiring the switch.

Specifications

  • Function: Off/(On)/(On), double momentary contact
  • LED colors: Off—blue; first on—green; second on—red
  • Switch rating: 20A, 12–24VDC
  • Material: Stainless steel
  • Waterproof rating: IP69K
  • Lead length: 4 feet
  • Mounting hole diameter: 22mm
  • Maximum mounting material thickness: 6mm
  • Mechanical life: 50,000 cycles
  • Electrical life: 10,000 cycles
  • Rear marking: Green dot

Good to know

The gasket comes with the switch. Allow for three button contact connections and two LED contact connections when installing it.

Specifications

Action(ON)-(ON)-OFF
ColorBlue/Green/Red
BrandBluewater
Manufacturer part #9059-2123-4
Boxed dimensions9 x 6 x 1 in
Shipping weight0.46 lb
