Bluewater 19mm Push Button Switch - Off/On/On Contact - Blue/Green/Red LED - 4' Lead

Bluewater 19mm Push Button Switch - Off/On/On Contact - Blue/Green/Red LED - 4' Lead

OM-BLUEWATER-19MMPUSHBUTTON-905731134

$68.28
$69.00 $68.28
Sale
FREE Standard Shipping On every U.S. order — no minimum. Faster delivery options are available at checkout for qualifying orders.

Low stock: 3 left
Free standard shipping · every U.S. order, no minimum
Sourced from authorized U.S. distributors
Genuine product · full manufacturer warranty
Secure checkout via Shopify Payments
View full details

Overview

ON-ON-OFFAction
Blue/Green/RedColor

Add push-button control to your boat's dash with the Bluewater 19mm Off/On/On Switch. Its blue, green and red LED indications help you identify the selected state, while the supplied gasket works with the switch body to provide an IP69K waterproof rating.

Key features

  • Off/On/On operation provides an off position and two on states.
  • Blue illumination indicates off, green indicates the first on state and red identifies the second on state.
  • Backlighting helps you locate the switch at night.
  • The body and included gasket provide IP69K protection against water.
  • A 4 ft lead provides length for routing the switch connection.

Specifications

  • Switch size: 19 mm
  • Contact function: Off/On/On, standard contact
  • LED colors: Blue / green / red
  • Switch rating: 15 A / 12–24 VDC
  • Material: Stainless steel
  • Lead length: 4 ft
  • Waterproof rating: IP69K with included gasket
  • Mechanical life: 50,000 cycles
  • Electrical life: 10,000 cycles
  • Mounting hole diameter: 19 mm
  • Maximum mounting material thickness: 6 mm
  • Button contacts: 3, color-coded
  • LED contacts: 2

Good to know

Installation requires a 19 mm hole in material no thicker than 6 mm. Wire the three button contacts and the two LED contacts; a gasket is included.

Specifications

ActionON-ON-OFF
ColorBlue/Green/Red
BrandBluewater
Manufacturer part #9057-3113-4
Boxed dimensions6 x 5 x 2 in
Shipping weight0.46 lb
