Blue Sea 7042 187 - Series Thermal Circuit Breaker - 80Amp

Blue Sea 7042 187 - Series Thermal Circuit Breaker - 80Amp

SKU:Blue-Sea-Systems-07234-20527

UPC: 632085170424
Regular price $77.53 USD
Regular price Sale price $77.53 USD
Sale Sold out
Tax included. Shipping calculated at checkout.
187 - Series Thermal Circuit Breakers - Panel Mount

80 Amp Circuit Breaker

PN:  7042

Features:
  • Combines switching and circuit protection into a single device
  • All components meet SAE J1171 external ignition protection requirements
  • Clear, single lever operation
  • "Trip Free" design cannot be held "ON" during fault current condition
  • Waterproof
  • Recessed mounting holes for clean appearance
  • Self-trimming case eliminates the need for mounting panels or trim bezels
  • Round case permits easy installation with standard sized hole saw
  • Large clearance around terminal studs accept heavy gauge wire lugs
  • Robust 5/16 terminals provide high torque connections
  • Large lever with vertical/horizontal orientation provides indication of trip status
  • Ignition protected - safe for installation aboard gasoline powered boats

Specifications
Circuit Breaker Class: Type III - Switchable / Manual Reset - Trip Free
Type: Thermally Responsive Bi-Metal Blade
Case Material: Thermoset Polyester
Voltage Rating: 48 Volts DC Maximum
Interrupt Rating: 5,000 Amperes @12 Volts DC
  3,000 Amperes @24 Volts DC
  1,500 Amperes @42 Volts DC
Operating Temperature Range: -25C° to +82C°
