• Blue Sea Push Button Reset Only Screw Terminal Circuit Breaker - 25 Amps
1 1

Blue Sea Systems

Blue Sea Push Button Reset Only Screw Terminal Circuit Breaker - 25 Amps

Blue Sea Push Button Reset Only Screw Terminal Circuit Breaker - 25 Amps

OM-BLUESEA-PUSHBUTTONRESE-2135

$18.52
$18.52
Shipping calculated at checkout.

Low stock: 3 left
Authorized Blue Sea Systems Dealer
Genuine product · full manufacturer warranty
Secure checkout via Shopify Payments
View full details

Overview

25aAmperage

This Blue Sea Systems push-button circuit breaker provides 25 amp DC circuit protection in a compact panel-mount format. It is a thermal trip breaker with manual reset operation, screw terminals, and ignition protection for gasoline-powered boats.

  • Amperage: 25A
  • Maximum voltage: 32V DC
  • Mounting: panel mount 3/8-27 UNS
  • Breaker type: thermal trip, manual push-button reset only
  • Terminal type: #8 screw
  • Interrupt capacity: 3000A at 14.7V / 2500A at 28V
  • Operating temperature: -10 degrees C to 60 degrees C
  • Screw terminal torque: 6 in-lb (0.68 Nm)
  • Weight: 0.09 lb (0.04 kg)
  • Design: trip-free construction cannot be held ON during a fault current condition
  • Use: branch circuit protection and 24-hour circuit protection
  • Compatibility: used in Blue Sea Systems WeatherDeck Waterproof Circuit Breaker Panels, Dual Battery Bank Main Distribution Panels, and 360 Distribution Panels
  • Optional accessory: push button waterproof boot replaces dress nut mounting and helps protect the breaker in wet environments

Specifications

Amperage25a
BrandBlue Sea Systems
Manufacturer part #2135
UPC632085021351
Boxed dimensions5 x 3 x 1 in
Shipping weight0.1 lb
Country of originMEXICO
