• Blue Sea 8084 AC Main +6 Positions/DC Main +15 Positions Toggle Circuit Breaker Panel - White Switches
1 1

Blue Sea Systems

Blue Sea 8084 AC Main +6 Positions/DC Main +15 Positions Toggle Circuit Breaker Panel - White Switches

Blue Sea 8084 AC Main +6 Positions/DC Main +15 Positions Toggle Circuit Breaker Panel - White Switches

OM-BLUESEA-8084ACMAIN-8084

$976.98
$1,620.99 $976.98
Sale
FREE Standard Shipping On every U.S. order — no minimum. Faster delivery options are available at checkout for qualifying orders.

Low stock: 1 left
Free standard shipping · every U.S. order, no minimum
Authorized Blue Sea Systems Dealer
Genuine product · full manufacturer warranty
Secure checkout via Shopify Payments
View full details

Overview

6 AC / 15 DCMax Breaker Quantity
BothAC/DC
120v/12vVoltage

The Blue Sea Systems 8084 panel combines AC and DC circuit control in one pre-wired marine panel. It is set up with an AC main plus 6 positions and a DC main plus 15 positions, using white toggle switches.

  • Model: 8084
  • Panel layout: AC Main +6 positions and DC Main +15 positions
  • Switch color: White
  • Maximum panel amperage: 100 amperes DC and 50 amperes AC
  • Voltage: 120 volts AC and 12 volts DC
  • Included AC breakers: 1 x 30A and 3 x 15A
  • Included DC breakers: 1 x 100A and 9 x 15A
  • Labels: Includes 30 common AC labels and 30 common DC labels
  • Wiring: AC and DC buses are installed and fully pre-wired
  • Lighting: Label backlighting and LEDs are pre-installed
  • AC features: Red reverse polarity LED, ready for optional 4029 AC Isolation Cover, and 9353 0-150 volt AC voltmeter
  • DC features: 100 amp C-Series main breaker, 8003 8-16 volt DC voltmeter, and 8017 0-100 amp DC ammeter
  • Upgrade option: Owner-upgradeable to 24 volts with 8240 18-32 volt DC voltmeter
  • ABYC note: Combined AC/DC panels require an AC insulating cover to meet ABYC standards

Specifications

Max Breaker Quantity6 AC / 15 DC
AC/DCBoth
Voltage120v/12v
BrandBlue Sea Systems
Manufacturer part #8084
UPC632085080846
Boxed dimensions23 x 15 x 7 in
Shipping weight8.6 lb
Country of originUNITED STATES
⚠ California Prop 65 Warning: WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Manuals & documents

Owner's manualPDF ↓
