Blue Sea 7146 187 - Series Thermal Circuit Breaker - 120Amp

Blue Sea 7146 187 - Series Thermal Circuit Breaker - 120Amp

OM-BLUESEA-7146187SERIES-7146

$93.57
$125.99 $93.57
Sale
FREE Standard Shipping On every U.S. order — no minimum. Faster delivery options are available at checkout for qualifying orders.

Low stock: 3 left
Free standard shipping · every U.S. order, no minimum
Authorized Blue Sea Systems Dealer
Genuine product · full manufacturer warranty
Secure checkout via Shopify Payments
View full details

Overview

120aAmperage

The Blue Sea Systems 7146 is a 187-Series surface mount thermal circuit breaker rated for 120 amps. It combines manual switching with circuit protection for DC electrical systems and is ignition protected for use aboard gasoline powered boats.

  • Brand: Blue Sea Systems
  • Part number: 7146
  • Series: 187-Series
  • Mounting: Surface mount
  • Rating: 120 Amp
  • Circuit breaker class: Type III switchable, manual reset, trip free
  • Type: Thermally responsive bi-metal blade
  • Case material: Thermoset polyester
  • Voltage rating: 48 Volts DC
  • Maximum interrupt rating: 5,000 Amperes at 12 Volts DC; 3,000 Amperes at 24 Volts DC; 1,500 Amperes at 42 Volts DC
  • Operating temperature range: -25C to +82C
  • Terminals: 5/16 terminals
  • Protection: Waterproof and ignition protected
  • Standards: Components meet SAE J1171 external ignition protection requirements
  • Design notes: Clear single-lever operation, recessed mounting holes, large terminal-stud clearance, and trip status indication by lever orientation
  • Warning: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (DEHP), known to the State of California to cause cancer, birth defects, or other reproductive harm.

Specifications

Amperage120a
BrandBlue Sea Systems
Manufacturer part #7146
UPC632085071462
Boxed dimensions5 x 4 x 2 in
Shipping weight0.5 lb
Country of originMEXICO
