• Blue Sea 7144 187 - Series Thermal Circuit Breaker - 100Amp
1 1

Blue Sea Systems

Blue Sea 7144 187 - Series Thermal Circuit Breaker - 100Amp

Blue Sea 7144 187 - Series Thermal Circuit Breaker - 100Amp

OM-BLUESEA-7144187SERIES-7144

$93.57
$125.99 $93.57
Sale
FREE Standard Shipping On every U.S. order — no minimum. Faster delivery options are available at checkout for qualifying orders.

Low stock: 3 left
Free standard shipping · every U.S. order, no minimum
Sourced from authorized U.S. distributors
Genuine product · full manufacturer warranty
Secure checkout via Shopify Payments
View full details

Overview

100aAmperage

The Blue Sea Systems 7144 is a 100 Amp 187-Series thermal circuit breaker for surface-mount marine electrical installations. It combines manual switching with circuit protection in one waterproof, ignition-protected device for DC systems.

  • Brand: Blue Sea Systems
  • Part number: 7144
  • Series: 187-Series
  • Amperage: 100 Amp
  • Mounting: Surface mount
  • Circuit breaker class: Type III - Switchable / Manual Reset - Trip Free
  • Type: Thermally responsive bi-metal blade
  • Case material: Thermoset polyester
  • Voltage rating: 48 Volts DC
  • Interrupt rating: 5,000 Amperes @ 12 Volts DC; 3,000 Amperes @ 24 Volts DC; 1,500 Amperes @ 42 Volts DC
  • Operating temperature range: -25C to +82C
  • Ignition protection: Components meet SAE J1171 external ignition protection requirements
  • Trip-free design: Cannot be held ON during a fault current condition
  • Terminals: 5/16 terminals for high-torque connections
  • Wire lug clearance: Large clearance around terminal studs accepts heavy gauge wire lugs
  • Lever: Clear single-lever operation with vertical/horizontal trip status indication
  • Mounting detail: Recessed mounting holes
  • Waterproof: Yes

Specifications

Amperage100a
BrandBlue Sea Systems
Manufacturer part #7144
UPC632085171445
Boxed dimensions8 x 3 x 2 in
Shipping weight0.2 lb
Country of originMEXICO
