• Blue Sea 7140 187 - Series Thermal Circuit Breaker - 60Amp
1 1

Blue Sea Systems

Blue Sea 7140 187 - Series Thermal Circuit Breaker - 60Amp

Blue Sea 7140 187 - Series Thermal Circuit Breaker - 60Amp

OM-BLUESEA-7140187SERIES-7140

$93.57
$125.99 $93.57
Sale
Shipping calculated at checkout.

Low stock: 3 left
Authorized Blue Sea Systems Dealer
Genuine product · full manufacturer warranty
Secure checkout via Shopify Payments
View full details

Overview

60aAmperage

The Blue Sea Systems 7140 is a 60 amp, surface-mount thermal circuit breaker for DC marine electrical systems. It combines manual switching with circuit protection in one waterproof device and is ignition protected for use on gasoline powered boats.

  • Part number: 7140
  • Series: 187 Series
  • Rating: 60 amp
  • Breaker class: Type III, switchable, manual reset, trip free
  • Type: thermally responsive bi-metal blade
  • Case material: thermoset polyester
  • Voltage rating: 48V DC maximum
  • Interrupt rating: 5,000A at 12V DC; 3,000A at 24V DC; 1,500A at 42V DC
  • Operating temperature: -25C to +82C
  • Terminals: 5/16 inch terminals for high torque connections
  • Design: trip-free mechanism cannot be held on during a fault current condition
  • Compliance: components meet SAE J1171 external ignition protection requirements
  • Warning: this product can expose you to chemicals including di(2-ethylhexyl)phthalate (DEHP), known to the State of California to cause cancer, birth defects, or other reproductive harm

Specifications

Amperage60a
BrandBlue Sea Systems
Manufacturer part #7140
UPC632085171407
Boxed dimensions8 x 5 x 2 in
Shipping weight0.6 lb
Country of originMEXICO
