• Blue Sea 7049 200 Amp Panel Mount 187 Series Circuit Breaker
1 1

Blue Sea Systems

Blue Sea 7049 200 Amp Panel Mount 187 Series Circuit Breaker

Blue Sea 7049 200 Amp Panel Mount 187 Series Circuit Breaker

OM-BLUESEA-7049200AMP-7049

$120.03
$164.99 $120.03
Sale
Shipping calculated at checkout.

Low stock: 3 left
Authorized Blue Sea Systems Dealer
Genuine product · full manufacturer warranty
Secure checkout via Shopify Payments
View full details

Overview

200aAmperage

The Blue Sea Systems 7049 is a 200 amp 187 Series panel-mount circuit breaker for DC marine electrical systems. It combines manual switching with circuit protection in one device and uses a clear single-lever design for easy trip-status checking.

  • Amperage: 200 amp
  • Maximum voltage rating: 48 volts DC
  • Interrupt rating: 5,000A at 12V DC, 3,000A at 24V DC, 1,500A at 42V DC
  • Breaker type: thermally responsive bi-metal blade
  • Breaker class: Type III, switchable/manual reset, trip free
  • Terminals: robust 5/16 M8 terminals with 5/16"-18 terminal studs
  • Terminal stud torque: 75 in-lb
  • Mounting holes: accept #10 M5 screws
  • Operating temperature range: -40C to 85C
  • Case material: thermoset polyester
  • Weight: 0.50 lb 0.23 kg
  • Installation notes: waterproof, ignition protected, recessed mounting holes, and clearance for heavy gauge wire lugs
  • Warning: This product can expose users to di(2-ethylhexyl)phthalate DEHP, known to the State of California to cause cancer, birth defects, or other reproductive harm.

Specifications

Amperage200a
BrandBlue Sea Systems
Manufacturer part #7049
UPC632085070496
Boxed dimensions8 x 5 x 3 in
Shipping weight0.5 lb
Country of originMEXICO
⚠ California Prop 65 Warning: WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.
