• Blue Sea 7042 187-Series Circuit Breaker - Panel Mount 80A
1 1

Blue Sea Systems

Blue Sea 7042 187-Series Circuit Breaker - Panel Mount 80A

Blue Sea 7042 187-Series Circuit Breaker - Panel Mount 80A

OM-BLUESEA-7042187SERIES-7042

$93.57
$125.99 $93.57
Sale
FREE Standard Shipping On every U.S. order — no minimum. Faster delivery options are available at checkout for qualifying orders.

Low stock: 3 left
Free standard shipping · every U.S. order, no minimum
Sourced from authorized U.S. distributors
Genuine product · full manufacturer warranty
Secure checkout via Shopify Payments
View full details

Overview

80aAmperage

Handle circuit protection and manual switching with the Blue Sea Systems 7042 187-Series 80A circuit breaker. This waterproof, panel-mounted unit is ignition-protected for installation aboard gasoline-powered boats, with a single lever for operation and trip indication.

Key features

  • Combined switching and circuit protection put both functions in one device.
  • A trip-free mechanism prevents the breaker from being held on during a fault-current condition.
  • The large lever shows trip status through its vertical or horizontal position.
  • Clearance around the terminal studs accommodates heavy-gauge wire lugs.
  • Recessed mounting holes give the installed panel a tidy appearance.
  • Waterproof construction and ignition protection suit marine installation.

Specifications

  • Model: 7042
  • Series: 187
  • Amperage: 80A
  • Maximum voltage: 48V DC
  • Mounting: Panel mount
  • Breaker mechanism: Thermally responsive bi-metal blade
  • Breaker class: Type III, switchable/manual reset, trip-free
  • Interrupt capacity: 5000A at 14V DC; 3000A at 28V DC; 1500A at 48V DC
  • Terminal stud size: 5/16 inch - 18
  • Terminal stud torque: 75 in-lb (8.47 Nm)
  • Mounting screw size: #10 (M5)
  • Operating temperature: -40°C to 85°C
  • Case material: Thermoset polyester
  • Weight: 0.50 lb (0.23 kg)

Good to know

Do not use this breaker as a switch in applications where high inrush currents are expected.

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov .

Specifications

Amperage80a
BrandBlue Sea Systems
Manufacturer part #7042
UPC632085170424
Boxed dimensions8 x 5 x 2 in
Shipping weight0.5 lb
Country of originMEXICO
⚠ California Prop 65 Warning: WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.
