• Blue Sea 7036 187 - Series Thermal Circuit Breaker - 30Amp
1 1

Blue Sea Systems

Blue Sea 7036 187 - Series Thermal Circuit Breaker - 30Amp

Blue Sea 7036 187 - Series Thermal Circuit Breaker - 30Amp

OM-BLUESEA-7036187SERIES-7036

$93.57
$125.99 $93.57
Sale
FREE Standard Shipping On every U.S. order — no minimum. Faster delivery options are available at checkout for qualifying orders.

Low stock: 2 left
Free standard shipping · every U.S. order, no minimum
Authorized Blue Sea Systems Dealer
Genuine product · full manufacturer warranty
Secure checkout via Shopify Payments
View full details

Overview

30aAmperage

The Blue Sea Systems 7036 is a 30 amp 187-Series thermal circuit breaker for panel-mount electrical installations. It combines manual switching with circuit protection in one waterproof, ignition-protected breaker for DC systems.

  • Part number: 7036
  • 187-Series panel mount thermal circuit breaker
  • Rated current: 30 amp
  • Circuit breaker class: Type III, switchable, manual reset, trip free
  • Thermally responsive bi-metal blade design
  • Cannot be held on during a fault current condition
  • Voltage rating: 48 Volts DC
  • Maximum interrupt rating: 5,000 Amperes at 12 Volts DC; 3,000 Amperes at 24 Volts DC; 1,500 Amperes at 42 Volts DC
  • Operating temperature range: -25C to +82C
  • Case material: thermoset polyester
  • All components meet SAE J1171 external ignition protection requirements
  • Ignition protected for installation aboard gasoline powered boats
  • Waterproof construction
  • Recessed mounting holes and self-trimming case for a clean installation without separate mounting panels or trim bezels
  • Round case works with installation using a standard sized hole saw
  • Large clearance around terminal studs accepts heavy gauge wire lugs
  • 5/16 terminals support high torque connections
  • Large lever can be oriented vertically or horizontally and indicates trip status
  • WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate, also known as DEHP, which is known to the State of California to cause cancer, birth defects or other reproductive harm

Specifications

Amperage30a
BrandBlue Sea Systems
Manufacturer part #7036
UPC632085070366
Boxed dimensions8 x 5 x 2 in
Shipping weight0.45 lb
Country of originMEXICO
