BEP Pro Installer ANL Through Panel Fuse Holder - 500A

BEP Pro Installer ANL Through Panel Fuse Holder - 500A

OM-BEPMARINE-PROINSTALLERAN-778ANLTP

$75.68
$108.36 $75.68
Sale
Shipping calculated at checkout.

Low stock: 1 left
Authorized BEP Marine Dealer
Genuine product · full manufacturer warranty
Secure checkout via Shopify Payments
View full details

Overview

ANLFuse Type
Fuse HoldersType

The BEP Marine Pro Installer ANL through-panel fuse holder is made for high-current DC circuit protection on boats. It places the fuse where it can be inspected through a clear cover and accessed for replacement while supporting demanding onboard electronics and heavy-load wiring.

  • Fuse type: ANL or ANN very fast acting fuses
  • Current range: 35-500A
  • Voltage rating: 50 VDC, or lower if determined by the installed fuse
  • Interrupt rating: up to 3,000 Amps DC
  • Cable connection studs: 10mm (3/8")
  • Fuse mounting studs: 8mm (5/16"), also accepts 10mm (3/8") fuses
  • Base material: high-temperature, fiber-reinforced plastic for strength and chemical resistance
  • Cover material: clear polycarbonate with fuse viewing window and label recess for printed labels up to 12.7mm wide
  • Hardware: tinned CDA260 highly conductive brass integral studs with stainless steel nuts and washers
  • Connection design: radiused points allow back-to-back lugs at angles from -90 degrees to +90 degrees
  • Threading: all threads are metric, with anti-seize lubrication applied to studs to help prevent galling
  • Use cases: inverters, battery chargers, house-circuit main fusing, digital switching main feeds, and heavy-duty loads

Specifications

Fuse TypeANL
TypeFuse Holders
BrandBEP Marine
Manufacturer part #778-ANLTP
UPC843687006824
Boxed dimensions7 x 6 x 2 in
Shipping weight0.85 lb
Country of originCHINA
