Overview

For sailors routing rope aboard their boat, the Barton Marine Size 2 Single Cheek Block provides a plain-bearing sheave for lines up to 8mm in diameter. Its moulded acetal sheave turns on a large-diameter brass bearing to keep the rope moving under load.

Key features

  • A precision-moulded acetal sheave guides the rope as it travels through the block.
  • The large-diameter brass bearing supports free-running operation under load.
  • Accommodation for rope up to 8mm helps you match the block to your line.

Specifications

  • Block configuration: Size 2 single cheek block
  • Bearing type: Plain
  • Sheave material: Acetal
  • Bearing material: Brass
  • Sheave size: 35mm x 12mm
  • Maximum rope diameter: 8mm
  • Safe working load: 370kg / 815lbs
  • Breaking load: 740kg / 1630lbs
  • Length: 80mm
  • Weight: 73g

Specifications

BrandBarton Marine
Manufacturer part #N02160
UPC5035088080519
Boxed dimensions5 x 2 x 1 in
Shipping weight0.25 lb
Country of originUNITED KINGDOM
